規格名稱    規格內容
技術特性    Crossover frequencies: 450Hz, 3000Hz – 24dB/octave; 12000Hz – 18dB/octave
驅動單體    Low-frequency transducer: Dual 250mm (10") PolyPlas, shielded
Midrange transducer: 100mm (4") PolyPlas, shielded
High-frequency transducer: 19mm (3/4") Titanium-laminate dome, shielded; EOS waveguide
Ultrahigh-frequency transducer: 19mm (3/4") Polyester-film, ring-radiator, shielded; EOS waveguide
尺寸    高: 1149mm
寬: 305mm
深: 422mm
淨重    29 kg
頻率範圍    32 ~ 40k Hz
靈敏度    91 dB
額定阻抗    8 ohms
