Inputs: 5 XLR
Output Impedance: 200 Ω
Outputs - Main: 2 XLR
Noise (unweighted): -110 dB
Outputs - Tape: 1 XLR
Distortion at 2 V output: 0.005 %
Maximum Gain: 18 dB
Maximum Output Signal: 40 V
Global Feedback: None
Absolute Polarity: Switchable
Volume Control Resolution, Steps: 0.5 dB, 140
Power Consumption: 250 VA
Volume Control Number of Steps: 140
Dimensions: 19" x 5.75" x 15.5"
Frequency Response: 2 Hz to 200 kHz
Weight: 45 lb
Input Impedance (minimum): 100 kΩ
Tube Complement: 8 x 6H30
